10/100M转1口RS-485/422串口服务器(FT-BC-6311M)

产品概述
FT-BC-6311M系列串口通讯服务器，也叫终端服务器或串行服务器，是异步串行口RS485/422和以太网之间的一个转换器。是一个带有CPU和嵌入式OS及完整TCP/IP协议栈的独立智能设备。完成RS485/422和以太网之间的数据双向透明传输，可以让RS485/422串口设备立即联接网络。

规格参数
实现以太网络与RS-485/422的双向数据传输
集成1路RS-485/422通讯接口，支持300bps-921600bps的通讯速率
集成1路10M/100M以太网接口
供电接口：DC-JACK、5.08-3P凤凰端子
工作电压：DC 5V±5%
工作电流：≤ 80mA@5V
工作温度：-40~+85℃
储存温度：-40~+85℃
工作湿度：5~95%（无凝露）
储存湿度：5~95%（无凝露）
静电保护：空气 4kV，接触4kV
浪涌保护：串口600W

注：本产品有全国产化型号可选
Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
